702S 2 in 1 Handheld Digital Automotive Oscilloscope Multimeter, Single Channel 10MHZ Bandwidth,64Kbyte Record Length,48MSa/s High Sampling Rate，amp ohm Volt Meter Tester、Voltage/Current Test
- 2-in-1: The ZNZHNSI 702s is a single-channel handheld device with both oscilloscope and multimeter functionality, featuring a 2.8" IPS display, 10 Mhz bandwidth, 48 MSa/s fast real-time sampling rate, ±400 V input capability, 64Kb recording depth, and dual-mode switching between oscilloscope and multimeter. Easy to use and improves work efficiency.
- Multimeter Test Mode: 9999 count; AC Voltage: 0-750 V; DC Voltage: 0-999.9 V; DC/AC Current: 0-9.999 A; Resistance: 0-99.99 MΩ; Capacitance: Frequency: 0-99.99 kHZ; Temperature: -20°C - 1000°C; Diode, Continuity Measurement. Continuity Measurement. Multifunctional measuring instrument ideal for professionals, factories, schools, hobbyists and families.
- Superior design: double injection molded ABS and TPE reinforced construction for excellent impact resistance and long-lasting durability; 320*240 resolution; large font design for easy data reading; adjustable brightness for various measurements in complex environments.
- Waveform Storage and Viewing: The oscilloscope automatically stores the currently measured waveform data in the form of run number and image in the memory; connect the oscilloscope to the computer via TYPE-C cable, click on the USB flash drive and open the image folder, then you can access or download the waveforms to a safer location in the computer for easy backup and analysis.
- Waveform Storage and Viewing: The oscilloscope automatically stores the current measurement waveform data in the form of run number and image in the memory; connect the oscilloscope to the computer by connecting the TYPE-C cable, click on the USB flash drive and open the image folder to access or download the waveform to a safer location in the computer for easy backup and analysis. Auto Power Off: You can choose the auto power off time. Depends on the usage frequency.
-
Save 10% when you buy two or more items.
-
Get 5% off your next purchase.
-
Enjoy free delivery on orders above $200.
-
Orders are processed and shipped from Canberra
Estimate delivery times: 12-26 days (International).
3-6 days (Domestic)
3-6 days (Domestic)
Guaranteed Safe Checkout
30-Day Return Guarantee
Confidence-backed purchases with 30-day return support.
Confidence-backed purchases with 30-day return support.
Free return pickup available
We’ll handle returns from your doorstep at no extra cost.
AUD |
BRSRO2Y6CEHAO2DG |
Category |
Electrical , Tools & Testers , Multi Testers |
Tags |
Estimated shipping
Select a product to estimate shipping.The ZNZHNSI 702S is a versatile 2-in-1 handheld device combining the functionality of an oscilloscope and a multimeter. It’s designed to streamline your diagnostic work, offering a convenient and powerful tool for a variety of applications.
Key Highlights
- Dual Functionality: Measures both voltage, current, and resistance, as well as displays waveforms with an oscilloscope.
- High Sampling Rate: Features a 48 MSa/s sampling rate for accurate real-time data capture.
- Large Display: Equipped with a 2.8" IPS display for easy readability of measurements and waveforms.
- Robust Construction: Built with a durable double injection molded ABS and TPE reinforced design.
- Comprehensive Testing: Includes measurements for temperature, capacitance, diode testing, and continuity.
Useful Facts
- Brand: ZNZHNSI
- Bandwidth: 10 MHz
- Sampling Rate: 48 MSa/s
- Recording Depth: 64 KB
- Voltage Range: AC Voltage: 0-750 V; DC Voltage: 0-999.9 V
- Current Range: DC/AC Current: 0-9.999 A
- Compliance: Meets CTA III 1000V, CTA II 600V, and CE standards.
Good Fit For
- Automotive technicians
- Factory maintenance personnel
- Electronics hobbyists
- Students studying electrical engineering
- DIY enthusiasts
Product details
| Main Specification | |
|---|---|
| Specification Met | Ce or CTA III 1000V or CTA II 600V |
| Manufacturer | ZNZHNSI |
| Brand | ZNZHNSI |
| Number of Items | 10 |
| Included Components | Oscilloscopes Oscilloscope Probes Instruction manuals |
| Power Source | Battery Powered |
| Upper Temperature Rating | 1000 Degrees Celsius |
| Colour | 702s |
| Style | Modern |
| Item Weight | 0.71 Kilograms |
| Technical Details | |
| Part Number | 702S |
| Measurement Type | Multimeter |
| Item details | |
| Model Number | 702S |
| Style | |
| Style Name | Modern |
| Others | |
| Product Type | Multi Testers |
| Power Source Type | Battery Powered |
| Minimum Operating Voltage | 400 Volts (AC) |
