DWL3000XY-B 2-Axis Digital Machinist Level & Inclinometer with BLUETOOTH, 0.002”/ft (0.2mm/M) 6 Inch , Black
- Digi-Pas 2-AXIS WIRELESS Machinist Level replaces Old-fashioned Spirit Vial Levels. Tedious repetition of checking 'bubble' position between tiny graduation lines is NOW THINGS OF THE PAST
- WIRELESS pairs to Smartphones/PC (Basic PC software is FREE), INSTANTLY read both X&Y leveling status (Digital & Graphic Animation) on your PC/phone while SIMULTANEOUSLY adjusting machine’s footings
- RESOLUTION: 0.002”/ft or 40-second (0.18 mm/M or 0.01°). Measurement range: 0° to ± 90.00°1-Axis; 0° to ± 10.00°2-Axis; Accuracy: ±0.002”/ft (± 0.01°) from 0° to ± 10.00°; ± 0.03° at other angles
- Additional Professional Software (DWL3000XY-SW) for full features on data display & logging saved in Excel format for further analysis. Built-in vibro-meter to detect relative vibration magnitude
- For users who needs a NIST-traceable Calibration Certificate with data, please visit our website for reference sample certificates and contact our sales support team.
-
Save 10% when you buy two or more items.
-
Get 5% off your next purchase.
-
Enjoy free delivery on orders above $200.
-
Orders are processed and shipped from Canberra
3-6 days (Domestic)
Confidence-backed purchases with 30-day return support.
AUD |
BRSWI2QROB7RC2QV |
Category |
Measuring & Layout Tools , Levels |
Tags |
Estimated shipping
Select a product to estimate shipping.WIRELESSLY LEVELLING CNC MACHINE
LEVELING & ALIGNMENT are vital processes in precision machines, image-capturing measurement & testing equipment. Imprecise leveling affects machine's structural stability (inducing more VIBRATIONS ) during active operation thus severely reduces dimensional accuracy and quality performances of outputs. In fact, without leveling a machine to its utmost precise condition, one could not ensure a machine’s own weight is proportionately distributed over its footings to achieve MAXIMUM STRUCTURAL STABILITY .
Digi-Pas DWL-3000XY & DWL3500XY are PREMIUM MID-PRECISION 2-Axis Digital Level with built-in Vibrometer for levelling, angle, alignment & vibration measurements, and performing real-time DATA ACQUISITION & DATA LOGGING with USB or WIRELESS Bluetooth connections. Acquired data can be saved into Microsoft Excel format for further analysis.
ADVANCED functional features are created to greatly simplifying the task for professionals & tradesmen in installation, set up and maintenance of precision machines, test/measuring instruments. It is a LEVELING & ANGULAR ALIGNMENT DIAGNOSTIC instrument used by many R&D engineers and scientists when performing alignment-sensitive equipment or machine to evaluate its STRUCTURAL STABILITY during either steady state or running state in real-time ( dynamic state).
Digi-Pas 2-axis Precision Digital Level is highly precise. To purchase an unit accompanied with NIST-traceable calibration certificate with data, please visit our website. This level come with 1-year mfr's free repair or exchange.
For over a decade, GRANTED with a portfolio of patents US Pat. No. 9,459,121 B, U.S. Pat. No. D 692,328 S, & Reg. No. 4,527,224 , Digi-Pas 2-axis digital level utilizing advanced MEMS technology has proven to effectively replace old-fashioned single-axis spirit vial levels. These MEDIUM & ULTRA PRECISION intelligent measuring instruments, including DWL8500XY and DWL5500XY & DWL5800XY Sensor Modules have been widely used by some of the world’s most technologically advanced companies, research laboratories and government institutions all over the world.
APPLICATIONS for INSTALLATION, SETUP and MAINTENANCE of precision CNC machines, Vision Measurement equipment, CT Scan and MRI equipment, Automotive & Semiconductor Manufacturing equipment, Precision Engineering Machinery etc.
Key Features
2-AXIS DISPLAY
Display Dual-Axis (X-Y) angle & vibration values in real-time on either instrument's screen or Laptop/mobilephone screens.
View 2-axis angle/leveling status SIMULTANEOUSLY in DIGITAL & Graphical "Bull Eye" Animation INSTANTLY.
EFFECTIVELY REPLACES 2 pieces of Old-fashioned Spirit Levels in one go.
WIRELESS
Tedious repetition on going ‘back-and-forth’ checking 'bubble' position in-between tiny graduation lines on Old-fashioned 'bubble' spirit vial is NOW THINGS OF THE PAST.
This task is replaced by WIRELESSLY looking at leveling status simultaneously on your smartphone screen while adjusting leveling or collecting data. It enables ONE-MAN OPERATION to align a machine instead of conventionally done by TWO MEN.
SOFTWARE & MOBILE APP
FREE version of PC Sync Software introduces basic single-axis angular and vibration readings monitoring.
Professional version of PC Sync Software enables BASIC & ADVANCED features for MONITORING, DATA LOGGING, RECORDING & ANALYSIS on leveling, angular and vibration readings via USB cables or wireless Bluetooth.
Data logging and recording features require use of PC Sync Professional Software.
For more info, please visit our website
VIBROMETER - GRAPH
Built-in Vibrometer for Real-time vibration patterns monitoring on device screen, for data logging, recording & analysis on PC.
Graphical displaying real-time LOW-FREQUENCY vibration data, effective for evaluating equipment or machine's STRUCTURAL STABILITY during running state in real-time (dynamic).
Allow to TRACK, MONITOR, RECORD & ANALYZE vibration patterns (relative Amplitude & frequency) in real-time condition (dynamic state).
Dual Power Sources
Use a rechargeable Battery Bank plugged into USB connector to significantly EXTEND your instrument operating hours.
When connected to external battery or USB source, the instrument automatically select external power source in order to preserve its internal AAA batteries.
PC SYNC PROFESSIONAL SOFTWARE & MOBILE APP
Professional version of PC Sync Software (OPTIONAL) enables for MONITORING, DATA LOGGING, RECORDING & ANALYSIS on leveling, angular and vibration real-time data via USB cables or wireless Bluetooth. Acquired data saved in Microsoft Excel format for further analysis.
Recorded data is useful for COMPARATIVE ANALYSIS on equipment or machines performance e.g. relative vibration density and amplitude, machine output yields analysis, changes in historical leveling values for machines during periodic maintenance etc. For more info, please visit our website.
DUAL-AXIS ANGULAR METER - REAL-TIME ANGULAR DATA VIEWING
This feature allows user to VIEW, TRACK & MONITOR dual-axis angle/leveling measurement SIMULTANEOUSLY in numerical and graphical in °(degree), mm/m & in/ft units concurrently on PC monitor via USB cable link or wireless Bluetooth link.
For more info, please visit our website.
DUAL-AXIS ANGLE GRAPH - REAL-TIME ANGULAR DATA CAPTURING
This feature allows user to VIEW, TRACK and RECORD 2-axis angle/leveling measurement simultaneously in graphical and numerical readings . User may define parameters (time interval for each sample taken, number of data collection, etc) for data CAPTURING and saved in Microsoft Excel format for further analysis.
VIBROMETER GRAPH - REAL-TIME VIBRATION DATA CAPTURING
This feature allows user to MONITOR, TRACK & RECORD vibration patterns of a machine/equipment/object in numerical and graphical forms (sampled at highest speed of ≤10mS and user may define parameters to capture different set of data).
Vibration readings can be saved in Microsoft Excel format for further analysis.
Product details
| Main Specification | |
|---|---|
| Manufacturer | DigiPas |
| Unit Count | 1 Count |
| Brand | Digi-Pas |
| Number of Items | 1 |
| Operation Mode | automatic |
| Included Components | Digital Level |
| Material | Polycarbonate |
| Colour | Black |
| Style | DWL3000XY-Bluetooth |
| Global Trade Identification Number | 08887726110273 |
| Item Weight | 1.3 pounds |
| Technical Details | |
| Manufacturer Part Number | Digi-Pas DWL 3000 XY |
| Material Type | Polycarbonate |
| Item details | |
| Model Number | DWL3000XY-B |
| Item Type Name | Machinist Level BT |
| Manufacturer Warranty Description | 2 years warranty against manufacturing defects |
| Style | |
| Style Name | DWL3000XY-Bluetooth |
| Others | |
| Product Type | Machinist Level BT |
| Level Measurement Units | degree |
| Level Measurement Type | digital |
